MODEL TL-4902

International size reference : 1/2AA, ER14252


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 0.5mA, TO 2V 1.2Ah
Rated voltage 3.6V
Rated 1 sec. pulse capability 20mA
Weight 9.2g (0.324oz.)
Volume 4.3 cc
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193


AVAILABLE TERMINATIONS
SUFFIX- /S STANDARD
SUFFIX- /P AXIAL PINS
SUFFIX- /T SOLDER TABS
SUFFIX- /PT2 RADIAL PINS
SUFFIX- /PT/TP POLARIZED TABS
