MODEL TL-4986

International size reference :ER22G68


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 0.5mA TO 2V 0.4Ah
Rated voltage 3.6V
Rated 1 sec. pulse capability 5mA
Weight 5.3g(.187oz.)
Volume 1.2 cc
Operating temperature range -55'C to +75'C
U.L. Component recognition MH 12193


AVAILABLE TERMINATIONS
SUFFIX- /S STANDARD
SUFFIX- /P TINNED NIKEL PINS



Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
