MODEL TL-5137

International size reference :DD, ER32L1245


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 10mA TO 2V 35Ah
Rated voltage 3.6V
Maximum continuous current 450mA
Maximum pulse current capability 1000mA
Rated 1 sec. pulse capability (to 3V) 200mA
Weight 195g (6.88oz.)
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193


AVAILABLE TERMINATIONS
SUFFIX- /S STANDARD
SUFFIX- /T SOLDER TABS
