MODEL TL-5186

International size reference :ER22G68


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 0.3mA TO 2V 0.4Ah
Rated voltage 3.6V
Weight 5.3g (0.187 oz.)
Volume 1.2 cc
Operating temperature range -55'C to +75'C
U.L. Component recognition MH 12193


AVAILABLE TERMINATION
SUFFIX- /P TINNED NIKEL PINS
