For Memory Back-up Applications


(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 2 mA, TO 2V 2.1Ah
Rated voltage 3.6V
Wires AWG 24
Enclosure UL 94V2
Mounting Hook & Loop Fastner
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193

Connector Type
Housing BERG 71627-001
Contacts BERG 47565-002

Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
