MODEL TL-5276/W

Utility Metering Memory Back-up Applications


TECHNICAL DATA

(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 1 mA TO 2V 0.95 Ah
Rated voltage 3.6V
Maximum continuous current 50mA
Maximum pulse current capability 100mA
Rated 1 sec. pulse capability 20mA
Enclosure Lexxan 143 UV stable
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193


Connector Type
IDC 1308 -102-426



Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
