For Utility Metering Applications


(Typical Values @+25'C for batteries stored for one year or less)

Nominal capacity @ 4 mA TO 2V 8.5 Ah
Rated voltage 3.6V
Maximum continuous current 230mA
Maximum pulse current capability 400mA
Rated 1 sec. pulse capability (to 3V) 60mA
Weight 55g (1.94 oz.)
Operating temperature range -55'C to +85'C
U.L. Component recognition MH 12193

Connector Type
Housing Molex 50-57-9402
Contacts Molex 16-02-0086

Note: Any representations in this website concerning performance, are for informational purposes only and are not
construed as warranties either expressed or implied, of future performance.
